HIKVISION DS-7332HQHI-K4 Quick Start Guide

Digital Video Recorder Quick Start Guide
4
Chapter 1 Rear Panel Interfaces Description
The rear panel interfaces vary with different models. Refer to Table 1-1 for the common interfaces description
of rear panels.
Table 1-1 Common Interfaces Description of Rear Panels
Chapter 2 Installation and Connections
2.1 DVR Installation
During installation of the DVR:
 Use brackets for rack mounting.
 Ensure ample room for audio and video cables.
 When routing cables, ensure that the bend radius of the cables are no less than five times than its
diameter.
 Connect the alarm cable.
 Allow at least 2 cm (≈0.75-inch) of space between racks mounted devices.
 Ensure the DVR is grounded.
 Environmental temperature should be within the range of -10 to +55º C, +14 to +131º F.
 Environmental humidity should be within the range of 10% to 90%.
Item
Description
Item
Description
VIDEO IN
BNC interface for Turbo HD and analog
video input
VIDEO OUT
BNC connector for video output
AUDIO IN
RCA connector
AUDIO OUT
RCA connector
LINE IN
Connector for two-way audio input
USB
Interface
Universal Serial Bus (USB) port
for additional devices
VGA
DB15 connector for VGA output.
Displays local video output and menu.
HDMI
HDMI video output connector
RS-485
Interface
Connector for RS-485 devices
RS-232
Interface
Connector for RS-232 devices
LAN
Connector for network
eSATA
Storage and expansion interface
for record or backup
ALARM
IN/OUT
Connector for alarm input/output
GND
Ground
Power
Switch
Switch for turning on/off the device
Power
Supply
100 to 240 VAC, 48 VDC, or 12
VDC for different models

HIKVISION DS-7332HQHI-K4 Specifications

General

Bit rate	64 Kbit/s
Product color	Black
Remote viewing	Yes
Maximum frame rate	30 fps
Audio formats supported	G.711 μ-law
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Playback resolutions supported	3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Number of simultaneously playbacked channels	16 channels
Audio input	5
BNC input ports	32
BNC output ports	1
Alarm input channels	16
Video input channels	32 channels
Alarm output channels	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of users	128 user(s)
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	Serial ATA
Maximum HDD capacity	10000 GB
AC input voltage	100 - 240 V
Power supply type	AC
Power consumption (max)	74 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	390 mm
Width	440 mm
Height	70 mm
Weight	7000 g
