HIKVISION DS-7604NI-E1 Quick Start Guide

www.hikvision.com/en/us
Stream Type allows enable/disable the audio streaming from the cameras (if the camera does
not have audio capabilities, then the Stream Type will only have Video option)
Resolution allows setting of the recording resolution
Bitrate Type allows the NVR to save HDD space when set to Variable (Available choses:
Variable and Constant)
Video Quality adjusts picture clarity (medium setting (3 green squares) is recommended.
Medium setting is the balance between good picture and saving HDD space).
Frame Rate allows setting of the recording frame rate (12-15 fps is recommended to save
HDD space and not to have a “choppy” image)
Max Bitrate Mode allows choosing between preset bitrate values and customizing the values
(General setting is recommended)
Max Bitrate (KBPS) is the chosen bitrate for streaming the video
Max Bitrate Recommended is the NVR’s recommended bitrate according to the parameters
set above.
Record Audio allows turning the audio recording on or off (this option is only available if the
camera has a microphone connected to it, or only the analog channels 1-4 on the hybrid NVR).
Video Stream allows changing the recording stream between Main Stream and Sub Stream
(this step requires a restart).
Please refer to the table below for recommended recording parameters
Resolution
Video Quality
Frame Rate (FPS)
Bitrate (KBPS)
320x240 (QVGA)
Medium (3 squares)
12-15
207
352x240 (CIF)
Medium (3 squares)
12-15
384
640x480 (VGA)
Medium (3 squares)
12-15
768
704x480 (4CIF)
Medium (3 squares)
12-15
1024
1280x720 (720P)
Medium (3 squares)
12-15
2048
1280x960 (960P)
Medium (3 squares)
12-15
2048
1600x1200 (2MP)
Medium (3 squares)
12-15
2560
1920x1080 (1080P)
Medium (3 squares)
12-15
3072
2048x1536 (3MP)
Medium (3 squares)
12-15
3072
2560x1920 (5MP)
Medium (3 squares)
8
4096

HIKVISION DS-7604NI-E1 Specifications

General

Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Video input channels	4 channels
Supported resolutions	1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
Video formats supported	H.264+
HDMI output	Yes
Card reader integrated	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Product color	Black
Rack capacity	1U
Output voltage	12 V
Power consumption (typical)	10 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
HDD capacity	- GB
HDD interface	Serial ATA
Maximum storage capacity	4 TB
Number of HDDs installed	0

Weight and Dimensions

Depth	230 mm
Width	315 mm
Height	45 mm
Weight	1000 g
