Quick Start Guide of Network Video Recorder
40
added.
3) Click Add to add the camera.
4) (For the encoders with multiple channels only) check the checkbox of Channel No. in the pop-up window,
as shown in the following figure, and click OK to finish adding.
One-touch RAID Configuration
Purpose:
The DS-8600/9600NI models support the RAID storage function. And for the DS-9600NI-RT/XT series NVR, the
disk array must be configured if you want to save recording and log files locally. Through one-touch configuration,
you can quickly create the disk array. By default, the array type to be created is RAID 5.
Before you start:
As the default array type is RAID 5, at least 3 HDDs must be installed in you device. And if more than 10 HDDs
are installed, 2 arrays can be configured.
Steps:
1. (For DS-9600NI-XT series only) Enable the RAID function by checking the checkbox in the disk mode
configuration interface.
Menu > HDD > Advanced
2. Enter the Physical Disk Settings interface.
Menu > HDD > RAID
3. Click One-touch Configuration to enter the One-touch Array Configuration interface.
4. Edit the array name in the Array Name text filed and click OK button to start configuring array.
If you install 4 HDDs or above for one-touch configuration, a hot spare disk will be set by default. It is
recommended to set hot spare disk for automatically rebuilding the array when the array is abnormal.
