HIKVISION DS-D5032QE - Connectivity and Ports; Signal Wire Connections

12
Control button and joint
Signal wire
• Connect the VGA wire:
Connect the 15 -pin VGA signal wire to the
back of the display and the VGA port of the computer or other devices.
• Connect the HDMI wire:
Connect the 19 -pin HDMI signal wire to the
back of the display and the HDMI port of the computer or other devices.
• Connect power cord:
Connect the power cord to the AC jack on the
back of the display.
1
2
3
4
RS232
HDMI
D-SUB
1.
Audio in
2.
D-SUB
3.
HDMI signal input
4.
RS232 (Serial port com-
munication control)
