HIKVISION DS-D5032QE User Manual

17
Problems Feasible solution
Flawed image color (the white
color does not look white)
• Please adjust the RGB color or select
color temperature.
Poor brightness or contrast
• When the display fades in brightness
and affects the display function after
being used for a period of time, please
hand the display to a qualied repair
center for repair.
The display has horizontal or
vertical interference
• Please adjust “Frequency” and “Phase”
or execute the shortcut key (automatic
button).
“Clock” (pixel frequency) can control the pixels scanned by a
single horizontal scanner. In the case of frequency error, vertical
strips appear on the display, and an abnormal image ratio will
be caused.

HIKVISION DS-D5032QE Specifications

General

3D	No
Panel type	-
Pixel pitch	0.36375 x 0.36375 mm
Screen shape	Flat
Response time	8 ms
Display diagonal	31.5 \
Display technology	LED
Maximum refresh rate	60 Hz
Supported video modes	1080p
Viewable size, vertical	392.85 mm
Contrast ratio (typical)	1400:1
Display number of colors	16.78 million colors
Viewable size, horizontal	698.4 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
On/off switch	Yes
Exterior finish material	Plastic
Product color	Black
Market positioning	Business
DisplayPorts quantity	0
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	55 W
RMS rated power	10 W
Number of speakers	2
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Panel mounting interface	100 x 100 mm
Package depth	136 mm
Package width	804 mm
Package height	500 mm
Package weight	6763 g
Cables included	AC
Harmonized System (HS) code	85285210

Weight and Dimensions

Height (with stand)	474 mm
Depth (without stand)	64 mm
Width (without stand)	727 mm
Height (without stand)	424 mm
Weight (without stand)	5090 g
