HIKVISION DS-K1T341CMF User Manual

Note
●
You should set the face recognion terminal's Wiegand direcon as Input to connect to a
Wiegand card reader. If connects to an access controller, you should set the Wiegand direcon as
Output to transmit authencaon informaon to the access controller.
●
For details about Wiegand
direcon sengs, see Set Wiegand Parameters .
●
Do not wire the device to the electric supply directly.
4.3 Wire Secure Door Control Unit
You can connect the terminal with the secure door control unit.
The wiring diagram is as follows.
Figure 4-2 Secure Door Control Unit Wiring
Note
The secure door control unit should connect to an external power supply separately. The suggested
external power supply is 12V, 0.5A.
4.4 Wire Fire Module
4.4.1 Wiring Diagram of Door Open When Powering O
Lock Type: Anode Lock, Magnec Lock, and Electric Bolt (NO)
Security Type: Door Open When Powering O
Scenario: Installed in Fire Engine Access
DS-K1T341C Series Face Recognion Terminal User Manual
18

HIKVISION DS-K1T341CMF Specifications

General

Type	Face recognition terminal
Product color	Black, Silver
Cards capacity	3000 cards
Event capacity	150000
Access code reader	-
Authentication type	Access chip/card, Face recognition
Face recognition distance	0 - 2 m
Face recognition duration	0.2 s
Access chip/card reader type	Contact
International Protection (IP) code	IP65
Operating system installed	Linux
Screen shape	Flat
Display diagonal	4.3 \
Maximum resolution	272 x 480 pixels
Touchscreen technology	Capacitive
Total megapixels	2 MP
Ethernet LAN data rates	10, 100 Mbit/s
Power consumption (typical)	10 W
Operating temperature (T-T)	-30 - 60 °C
