Access Control Terminal·Quick Start Guide
4
Solid Red for a
time period
The operation of pressing
keys or swiping card is
invalid.
Numeric key 0 to 9, Clearing key *, and
Confirming key #
Wire the device with power supply, doorbell,
and door lock.
Control the status of the lock relay.
When rebooting the device, hold the button
for about 8s to enter the initialization mode.
When initializing, the device buzzer will beep
for 8s.
2.2 Description of Keypad Items
Description of Keys
Numeric Keys: Enter number in the
textbox.
Direction Keys: Select icons in the menu.
Exiting Key: Click the key to exit the
menu.
Confirming Key: Click the key to confirm
operations.
3 Terminal Connection
3.1 Terminal Description
The following table shows the terminals description:
To Next Page
