Access Control Terminal·Quick Start Guide
7
4 Installation
Before you start
Please make sure that the device in the package is in good
condition and all the assembly parts are included.
Make sure that all the related equipment is power-off during
the installation.
Check the specification of the products for the installation
environment.
Check whether the power supply is matched with your AC
outlet to avoid damage.
If the product does not function properly, please contact your
dealer or the nearest service center. Do not disassemble the
camera for repair or maintenance by yourself.
Please make sure the wall is strong enough to withstand three
times the weight of the camera and the mounting.
4.1 Mounting with Gang Box
Steps:
1. Route the cables through the cable hole of the mounting base.
2. Align the screw holes on mounting base with the screw holes
on gang box.
3. Fix the mounting base on the gang box with inserting two
KA4*22-SUS screws (supplied) into the two screw holes.
To Next Page
