HIKVISION DS-K2601

DS-K2600 Series Access Controller
8
Table 3-1 DS-K2601 Terminal Description
No.
DS-K2601
A1
Lock Power
GND
Grounding
A2
+12V
Power Output of the Lock
A3
Card Reader
Power
GND
Grounding
A4
+12V
Power Output of the Head Read
A5
Wiegand
Card Reader
2
GND
Grounding
A6
W0
Wiegand Head Read Data Input Data0
A7
W1
Wiegand Head Read Data Input Data1
A8
BZ
Card Reader Buzzer Control Output
A9
ERR
Indicator of Card Reader Control Output
(Invalid Card Output)
A10
OK
Indicator of Card Reader Control Output
(Valid Card Output)
A11
Wiegand
Card Reader
1
GND
Grounding
A12
W0
Wiegand Head Read Data Input Data0
A13
W1
Wiegand Head Read Data Input Data1
A14
BZ
Card Reader Buzzer Control Output
A15
ERR
Indicator of Card Reader Control Output
(Invalid Card Output)
A16
OK
Indicator of Card Reader Control Output
(Valid Card Output)
B1
Arming
Region
Input
Z1
Arming Region Access Terminal 1 (Only for
Linkage of Alarm Relay Output)
B2
GND
Grounding
