HIKVISION DS-K2M061 User Manual

Chapter 4 Installaon
Before installing the secure door control unit, please set the DIP switch and connect it with the
cable.
4.1 DIP Switch Descripon
Refer to Appearance Introducon for the posion of DIP switch. DIP switch descripon is as shown
in the following gure. No. 1 to 4 in the gure are switch No.
Figure 4-1 DIP Switch Descripon
DIP switch meaning is as shown in the following table.
Table 4-1 DIP Switch Meaning
Icon Meaning
Represent 0 in binary mode
Represent 1 in binary mode
As shown in the gure below, the binary number represented by the DIP switch 1234 is 0011,
which is the decimal address: 3.
DS-K2M061 Secure Door Control Unit User Manual
6

HIKVISION DS-K2M061 Specifications

General

Interface	RS-485
Compatibility	-
Product color	Black
Brand compatibility	Hikvision Digital Technology
Operating temperature (T-T)	-40 - 70 °C

Weight and Dimensions

Depth	115 mm
Width	48 mm
Height	26 mm
