HIKVISION DS-KH8350-TE1 User Manual

Chapter 2 Acvaon
2.1 Acvate via iVMS-4200 Client Soware
You can only congure and operate the indoor staon aer creang a password for the device
acvaon.
Before You Start
Default parameters of indoor staon are as follows:
●
Default IP Address: 192.0.0.64.
●
Default Port No.: 8000.
●
Default User Name: admin.
Steps
1.
Run the client
soware, enter Device Management, check the Online Device area.
2.
Select an inacvated device and click the Acvate.
3.
Create a password, and
conrm the password.
Note
We highly recommend you to create a strong password of your own choosing (using a minimum
of 8 characters, including at least three kinds of following categories: upper case leers, lower
case leers, numbers, and special characters) in order to increase the security of your product.
And we recommend you change your password regularly, especially in the high security system,
changing the password monthly or weekly can beer protect your product.
4.
Click OK to acvate the device.
Network Indoor Staon Conguraon Guide
2

HIKVISION DS-KH8350-TE1 Specifications

General

Color	Yes
Certification	FCC, IC, CE, C-TICK, REACH, WEEE, UL, CB, RCM
Connectivity technology	Wired
Sustainability certificates	RoHS
Number of displays supported	-
Voice codecs	G.711u
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Power consumption	200 mA
Indoor unit power type	DC
Power consumption (typical)	7 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	IPS
Proper use	Indoor
Product color	Black, Grey
Placement supported	Horizontal
Package weight	786 g
Outdoor unit included	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, SIP, RTSP

Weight and Dimensions

Depth	22.4 mm
Width	180 mm
Height	140 mm
Weight	600 g
