HIKVISION DS-KH8350-TE1 User Manual

Figure 4-4 Time Sengs Page
Select Time Zone, Enable NTP, Enable DST, or SDK Synchronizaon. Click Save to save the me
sengs.
●
Time Zone: Select a me zone from the drop-down list menu.
●
NTP: Click Enable NTP, and enter the server address, NTP port, and
synchronizaon interval.
Note
The default port No. is 123.
●
DST: Click Enable DST, and set the start
me, end me, and bias.
●
SDK Synchronizaon: Click Synchronizaon, and the system will synchronize the data to the SDK.
System Maintenance
Click
System Maintenance to enter the page.
Network Indoor Staon Conguraon Guide
46

HIKVISION DS-KH8350-TE1 Specifications

General

Color	Yes
Certification	FCC, IC, CE, C-TICK, REACH, WEEE, UL, CB, RCM
Connectivity technology	Wired
Sustainability certificates	RoHS
Number of displays supported	-
Voice codecs	G.711u
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Power consumption	200 mA
Indoor unit power type	DC
Power consumption (typical)	7 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	IPS
Proper use	Indoor
Product color	Black, Grey
Placement supported	Horizontal
Package weight	786 g
Outdoor unit included	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, SIP, RTSP

Weight and Dimensions

Depth	22.4 mm
Width	180 mm
Height	140 mm
Weight	600 g
