2-Wire
Model DS-KD8003-
IME2
DS-KD-DIS DS-KD-KP DS-KD-M /
Quanty 1 1 2 2 /
Power 4 W 2.5 W 2 W 1.6 W Total: 10.1 W
Because 10.1 W ≤ 16 W, we can support powering this device through KAD706 channel 6 or
KAD704 channel 4.
2-Wire
Model DS-KD8003-IME2 DS-KD-M DS-KD-KK /
Quanty 1 1 12 /
Power 4 W 0.8 W 9.6 W Total: 14.4 W
Because 14.4 W ≤ 16 W, we can support powering this device through KAD706 channel 6 or
KAD704 channel 4.
Wire
Tesng Standards
●
When there are mulple cores in one parallel line, only one pair of closed cores are allowed to
transmit signal. It is not allowed to use
mulple pair of cores in one cable to transmit signal.
●
When using parallel lines, it is suggested to use those with shielding layer. If dual core or mulple
core parallel lines without shielding layer are routed, stability of signal transmission can be
eected. You need to run a test before installaon.
●
Impedance of twist pair in network cable are over 42 Ω/100 m, so network cable cannot
transmit enough power to indoor
staon. Network cable is not allowed to use during
installaon.
●
Strong electricity and weak electricity cannot be wired in the same route, they need to be wired
separately and the distance should be more than 0.5 meter.
Network Indoor Staon Conguraon Guide
70
