HIKVISION DS-KIS101-P/FLUSH User Manual

A. Cables
Cables and Wiring
●
When there are mulple cores in one parallel line, only one pair of closed
cores are allowed to transmit signal. It is not allowed to use mulple pair
of cores in one cable to transmit signal.
●
When using parallel lines, it is suggested to use those with shielding layer.
If dual core or mulple core parallel lines without shielding layer are
routed, stability of signal transmission can be eected. You need to run a
test before installaon.
●
Impedance of cable should not be over suggested value, or distributor
cannot transmit enough power to indoor staon or door staon.
●
Strong electricity and weak electricity cannot be wired in the same route,
they need to be wired separately and the distance should be more than
0.5 meter.
●
All the cables used need to follow the
restricon in the following table.
Table A-1 Wiring Cables A
Roung Path Twisted Pair
Door Staon-
Indoor Staon
24AWG (0.2
mm
2
)
20AWG (0.5
mm
2
)
18AWG (0.8
mm
2
)
16AWG (1
mm
2
)
Transmission
Distance ≤ 70
m
Transmission
Distance ≤
100 m
Transmission
Distance ≤
100 m
Transmission
Distance ≤
100 m
Video Intercom Analog Bundle User Manual
26
