4 Typical Applicaon
The typical applicaon of the device is shown as below.
Figure 4-1 Typical Applicaon
Wire the door staon to the indoor staon with 2-wire cables.
You can acvate door staon by indoor staon.
Set the open duraon and other parameters by indoor staon.
Refers to the Indoor Staon Conguraon Guide for details.
