Digital Video Recorder User Manual
202
1) Check the checkbox of Enable Unlock Pattern to enable the use of unlock pattern when
logging in to the device.
2) Use the mouse to draw a pattern among the 9 dots on the screen. Release the mouse when
the pattern is done.
3) Confirm the pattern again with the mouse.
Please refer to Chapter 2.3.1 Configuring the Unlock Pattern for detailed instructions.
Figure 15-12 Set Unlock Patter for Admin User
Step 6 (Optional) Click icon after Draw Unlock Pattern to modify the pattern.
Step 7 (Optional) Click icon after Export GUID to pop up the Reset Password interface. Click
Export button to export GUID to the USB flash drive for retrieving the forgotten password.
Then a GUID file will be saved in the USB flash drive.
Figure 15-13 Export GUID
You must input the correct old password of the admin before exporting GUID.
Step 8 Click the OK button to save the settings and exit from the menu.
