Digital Video Recorder User Manual
57
Figure 4-2 PTZ-General
Step 4 Select the parameters of the PTZ camera from the drop-down list.
All the parameters should be exactly the same as the PTZ camera parameters.
For the Coaxitron camera/dome connected, you can select the PTZ protocol to UTC
(Coaxitron). Make sure the protocol selected here is supported by the connected
camera/dome.
When the Coaxitron protocol is selected, all the other parameters like the baud rate, data bit,
stop bit, parity and flow control are not configurable.
When Hikvision CVBS camera is connected, you can control PTZ via Coaxitron.
Step 5 (Optional) Click Copy button to copy the settings to the other channels. Select the channels
you want to copy to and click OK to return to the PTZ Parameters Settings interface.
Figure 4-3 Copy to Other Channels
Step 6 Click OK to save the settings.
