HIKVISION iDS-2CD9396-BIS - 8.2 Set OSD Settings

Network Traffic Camera • User Manual
45
 Space: It stands for the length of blank space between the last character of the first item and
the first character of the next item.
 Line Break Characters: When you add Line Break Characters to an item, the item is displayed
as a new paragraph, and the number stands for the scale of space above the paragraph.
 / : Click to move the overlay position up. Click to move the overlay position
down.
Set OSD Settings
Purpose:
You can set the overlay information of the captured picture.
Go to Configuration > Device Configuration > Text Overlay > Picture Overlay
Configuration.
Capture Overlay Configuration
Set the parameters below.
 OSD Attribute: the OSD information attribute overlaid on the picture.
 OSD Size: the font size of the overlay information.
 Alignment: the OSD alignment mode, you can select Align Left. Align Right, International
Mode or Custom.
 Min. Boundary: the min. boundary value measured by character.
 Display Name: Device name.
 Time Format: 24-hour and 12-hour are selectable.
 Date Format: The date format overlaid on the picture.
