HIKVISION iDS-7700NXI-I4/16P/16S Series Quick Start Guide

Network Video Recorder Quick Start Guide
30
Figure 2-12 Fasten Hard Disk
Step 2 Insert the key and turn in clockwise direction to open the panel lock.
Step 3 Press the buttons on the panel of two sides and open the front panel.
Figure 2-13 Open Front Panel
Step 4 Insert the hard disk along the slot until it is placed into position.
Figure 2-14 Insert HDD to the Slot
Step 5 Repeat the above steps to install other hard disks onto the NVR.
Step 6 After having finished the installation of all hard disks, close the front panel and lock it with
the key again.
