4
Regulatory Information
This product and - if applicable - the supplied
accessories too are marked with "CE" and
comply therefore with the applicable
harmonized European standards listed under
the RE Direcve 2014/53/EU, the EMC
Direcve 2014/30/EU, the RoHS Direcve
2011/65/EU.
2012/19/EU (WEEE direcve): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European
Union. For proper recycling, return this product
to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at
designated collecon points. For more
informaon see: www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be disposed of as
unsorted municipal waste in the European Union. See the product documentaon for specific
baery informaon. The baery is marked with this symbol, which may include leering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the baery to
your supplier or to a designated collecon point. For more informaon see: www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to the following two condions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radioexempts de licence. L'exploitaon est autorisée aux deux
condions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est suscepble d'en compromere le fonconnement.
Under Industry Canada regulaons, this radio transmier may only operate using an antenna of a type and maximum (or lesser) gain approved for the
transmier by Industry Canada. To reduce potenal radio interference to other users, the antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communicaon.
Conformément à la réglementaon d'Industrie Canada, le présent émeeur radio peut
fonconner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émeeur par Industrie Canada. Dans le but de réduire les
risques de brouillage radioélectrique à l'intenon des autres ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communicaon sasfaisante.
This equipment should be installed and operated with a minimum distance 20cm between the radiator and your body.
Cet équipement doit être installé et ulisé à une distance minimale de 20 cm entre le radiateur et votre corps.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operaon.
EU Conformity Statement
ConfigurationDevice Wiring
Attendance Configuration
3
2
Access Control System Configuration
User Management
1
Note: The external power supply and the access control terminal should use the same GND cable.
Manage User: In the New (New User) interface, enter
the new user ID No., the user name, the card No. Register
the fingerprint, set the password, select the department,
set the user permission, select schedule template, set the
authencaon mode and set the duress card. Save the
parameters to confirm adding.
ACS System Configuration:
In the ACS Parameters Seng interface, configure the terminal authencaon mode, the sub reader authen-
caon mode, the door magnec status, the lock acon me, the door-open meout alarm, the maximum
mes for authencaon and the an-passback.
Holiday Group Configuration:
In New (New Holiday Group) interface, enter a new holiday group name. Select New ACS Holiday and enter
the holiday No., the holiday name, the holiday start me and the holiday end me. Save the parameters to
confirm adding.
Week Plan Configuration:
In the Week Plan menu, select New (New Week Plan) to configure the week plan parameters, including the
No., the name, the week plan me and the corresponding periods. Save the parameters to confirm adding.
Schedule Template Configuration:
In the Schedule Template menu, select New (New Schedule Template) to configure the schedule template
parameters, including the template No., the template name, the week plan and the holiday group. Save the
parameters to confirm adding.
Configure the shi via the device. You are able to
schedule shi by department or by individual depending
on the user property. The working flows are as follows:
Scheduling Shift by Department: Add User (See
Step 1) - Edit Department - Configure Shi - Add Holiday -
Configure Shi Schedule (by Department).
Edit Department: Select a department to edit in the department list. Select “Edit”and edit the department name, shi type and shi name. Save the parameters
Configure Shift
Normal Shi: In the Normal Shi interface, configure the aendance rule, the normal shi aendance. Save the parameters to confirm seng.
Man-Hour Shi: In the Man-Hour Shi interface, configure the man-hour shi parameters. Save the parameters to confirm seng.
Add Holiday
In the New (New Holiday) interface, enter the holiday No, the holiday name, the holiday start me and the holiday end me. Save the parameters to confirm adding.
Configure Shift Schedule
Schedule Shi by Department: Select a department to configure in the By Dept. (Schedule by Department) interface. Configure the shi, the start date, the end date and
the holiday. Save the parameters to confirm configuraon.
Schedule Shi by Individual: Select New Individual Shi in the By Indiv. (Schedule by Individual) interface. Select a person to schedule in the New Individual Shi
interface. Configure the shi, the schedule start date and the end date. Save the parameters to confirm eding.
User Management
ACS Configuraon
Aendance
Configuraon
External Device Wiring Overview (Without Secure Door Control Unit)
External Device Wiring Overview (With Secure Door Control Unit)
Door Status
Input
Power Input
SENSOR
BUTTON
B1
B2
B3
B4
Green/Brown
Black
Green/Black
Black
Lock Output
NC
C1
C2
C3
COM
NC
White/Purple
White/Black
White/Red
Red
Black
Door Magnec
Exit Buon
NO
Power
Electric Dropbolt/
Magnec Lock
Electric Strike
Secure Door Control Unit
Wiring Terminal
Note: The external power supply and the secure door control terminal should use the same GND cable.
Attendance Report
Plug the USB disk in the device. In Report interface of Aendance interface, select a table type to export. Press the OK key to export the aendance report to the USB disk.
The device will automacally check the USB disk memory. If there is no enough space for exporng, a prompt will be displayed. You are able to configure the record over
threshold prompt and record delete funcon in the System interface.
Record over Threshold Pop up Prompt (%): If the aendance record memory reaches the configured value, the system will pop up a prompt to remind you. If
configure the threshold to 99%, the system will pop up a prompt to remind you to delete the aendance data when the capacity reaches the threshold. The available
value: 1 to 99.
Record Delete: When the funcon is enabled, the terminal will delete the first 3000 aendance records when the memory is full, in order to save the new aendance
records. By default, the funcon is enabled. See Secon 5.2 Aendance Record Delete Rule in the User Manual of Fingerprint Time Aendance Terminal.
5
FCC Information
Please take aenon that changes or modificaon not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protecon against harmful interference in a residenal installaon. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instrucons,
may cause harmful interference to radio communicaons. However, there is no guarantee that
interference will not occur in a parcular installaon. If this equipment does cause harmful interference
to radio or television recepon, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
This equipment should be installed and operated with a minimum distance 20cm between the radiator
and your body.
Scheduling Shift by Individual: Add User (See Step 1) - Configure Shi - Add Holiday - Configure Shi Schedule (by Individual).
User Management, Access Control System Configuraon
and Aendance Configuraon are three main parts of the
Access Control Terminal.
