AIR FLOW

AND

PRODUCT LOADING

Cases have been designed to provide maxi-

mum product capacity within the refrigerated

air envelope. It is important that you do not

overload the food product display so that it

impinges on the air flow pattern.

DISCHARGE..............1

LOAD LIMIT...............2

AIR FLOW..................3

RETURN AIR GRILL...4

MODEL

O5DMA

Overloading will cause malfunction and the

loss of proper temperature levels, particular-

ly when discharge and return air sections are

covered. Please keep products within the

load limit lines shown on these diagrams.
