NOTES:
z FRONT SILL HEIGHT AND OVERALL CASE HEIGHT VARYS WITH BASEFRAME HEIGHT
z A 2" MINIMUM AIR GAP IS REQUIRED BETWEEN THE REAR OF THE CASE AND A WALL
z AVAILABLE SHELF SIZES: 10", 12", 14", 16", 18", 20", 22" & 24"
FRONT OF CASE
48 in [121.9 cm] {4' case}
72 in [182.9 cm] {6' case}
96 in [243.8 cm] {8' case}
43 1/4 in
[109.9 cm]
35 1/16 in
[89.0 cm]
31 9/16 in
[80.2 cm]
9 7/8 in
[25.1 cm]
CONDENSING UNIT
6 3/16 in [15.7 cm]
3 in [7.6 cm]
JUNCTION BOX
3 in [7.6 cm]
12 in
[30.5 cm]
39 1/4 in
[99.7 cm]
DRAIN PAN
DRAIN ASSEMBLY
1 1/2 in [3.8 cm]
{END}
3 in [7.6 cm]
C
L
39 11/16 in [100.7 cm]
5 1/8 in
[13.1 cm]
COIL
PLENUM
6 13/16 in [17.2 cm]*
43 1/4 in [109.9 cm]
32 in [81.3 cm]
59 in
[149.9 cm]
3rd ROW LIGHT
(OPTIONAL)
9.75" MIRROR
(OPTIONAL)
13" MIRROR
(OPTIONAL)
14 1/2 in
[36.9 cm]
18 11/16 in
[47.5 cm]
55 13/16 in
[141.7 cm]
THROAT
STANDARD
DAIRY FRONT
31 9/16 in [80.2 cm]
39 1/4 in [99.7 cm]
17 in
[43.2 cm]
21 3/16 in
[53.9 cm]
53 5/16 in [135.4 cm] THROAT 50 13/16 in [129.0 cm] THROAT
19 1/2 in
[49.6 cm]
23 11/16 in
[60.2 cm]
48 5/16 in [122.7 cm] THROAT
22 in
[55.9 cm]
26 3/16 in
[66.6 cm]
50 13/16 in [129.0 cm] THROAT
19 1/2 in
[49.6 cm]
23 11/16 in
[60.2 cm]
2 1/2" EXTENDED FRONT
W/ NOSE LIGHT
5" EXTENDED FRONT
5" EXTENDED FRONT
W/ NOSE LIGHT
7 1/2" EXTENDED FRONT
W/ NOSE LIGHT
102 7/8 in
[261.3 cm]
100 13/16 in
[256.1 cm]
19 3/16 in
[48.7 cm]
