Warning
This sprayer is designed for domestic use
only with water based garden chemicals.
Not to be used for any other purpose.
To be used by adults only.
Important: under normal use and conditions
the sprayer bottle has a maximum life
of ve (5) years after purchase date.
The purchase date, place of purchase and
product number should be recorded in this
Product Manual.
Contents
Refer to diagram on page 5 for parts listed.
1 x sprayer bottle assembly
1 x internal pump assembly
1 x lance assembly with nozzle
1 x product manual
1 x strip nozzle
1 x I.D. Tag (5 Litre and 8 Litre models only)
1 x I.D. Tag insert sheet (5 Litre and 8 Litre
models only)
Please retain this Product Manual. Record the following
information for future reference.
Product Number (printed on carton):
Date of purchase:
Name and location of store:
Made in China
®
Spare Parts
100710 – Nozzle and Lance Kit
100711 – Service Kit
Includes: bucket washer, pump valve, bucket
support washer, valve plunger, valve cap seal,
safety valve and O ring.
Accessories
100709 – Cone Spray Shield and Cup
100708 – Lawn Edger Shield
Two nozzles are included. One is for cone
spray pattern and one is for strip spray pattern.
Choose the one suitable for your particular
spraying application.
Introduction
