TRIDENT V12XP
Pos
PRODUCT
CODE
PRV NO. DESCRIPTION
100 86431200 5485HY POWER HEAD COVER V12XP, GRAY BLACK
101 86141500 5008GS EXHAUST FILTER CATCH, GRAY BLACK
102 86141450 5143 EXHAUST FILTER
103 86141480 5007GS EXHAUST FILTER COVER, GRAY BLACK
104 86146140 5727UL SWIVEL NECK ASSEMBLY
105 86143200 5258UL MALE CONTACT HOLDER
106 86147030 0102 SCREW M3,9x13 DIN 7981
107 86139230 2494 CABLE CLAMP
108 86145120 5101 SLEEVE
109 86146120 5480 SWIVEL NECK SUPPORT R. H.
110 86146110 5479 SWIVEL NECK SUPPORT L.H.
111 86146130 5717 SWIVEL NECK BEARING
112 86385730 5848ER 12V POWER SUPPLY 120V 3 WIRE
113 86385760 5205/1 RIBBON CABLE
114 86431250 5102LB BRUSH ROLLER RELEASE, LIGHT BLUE
115 86145290 5103 SPRING
116 86319350 5051SW AXLE ASSEMBLY, BLACK
117 86293260 5059OR FOOT PEDAL, ORANGE
118 86137990 5053 AXLE
119 86319360 5819SW WHEEL, BLACK
120 86146570 2010 WHEEL RETURN SPRING
121 86140000 2014 CLAMP CONNECTING ROD AXLE
122 86406130 5287SW BEARING BLOCK RIGHT HAND, BLACK
123 86004950 5010WI BRUSH ROLLER 12”
124 86319410 5005SW BUMPER BLACK (2PC V12S/XP)
125 86406140 5155SW RUBBING PLATE, BLACK
126 86137720 5172OR ACCESS DOOR ORANGE
127 86138000 5303 ACCESS DOOR AXEL
128 86145330 5304 SPRING, ACCESS DOOR
129 86406160 5154SW HINGE BLACK
130 86147150 0100 SCREW C 2,9x9,5,
131 86147170 0176 SCREW M4 x 30
132 86319380 5174SW PILE ADJUSTMENT WHEEL, BLACK
133 86145080 5060ER SERVO MOTOR WITH GEAR BOX
134 86406170 5411GS BOTTOM PLATE, FRONT,CPL.,GRAY BL, V12XP
135 86406180 5412GS BOTTOM PLATE, REAR, CPL., GRAY BL, V12XP
136 86144940 5400-1 SEALING STRIP 12”
137 86146790 5401 WIRE TIE, BOTTOM PLATE, OUTER
138 86146800 5402 WIRE TIE, BOTTOM PLATE, CENTER
139 86144850 0197 SCREW M4x12 MM WE/WASHER
140 86406190 5482SW CHASSIS, COMPL., BLACK
141 86143630 5469 MOTOR 1000 W / 120 V
- 86139400 05117S CARBON BRUSH SET 100/120V
- 86146210 05135ST THERMO SWITCH VAC
142 86144710 5100 RUBBER MOUNTING
143 86143620 5462 VACUUM MOTOR PULLEY 2MR
144 86145470 5129 SUPPORT LEVER
145 86145460 5107-1 SUPPORT SPRING
146 86143570 5112SW MOTOR PULLEY COVER
147 86385750 5849ER COMPUTER CONTROLLER 110-240V
148 86147160 0107 SCREW, 2.9x13
