Network Turret Camera·Quick Start Guide
19
this section. And you can take steps of wall mounting as a
reference for the ceiling mounting.
Steps:
1. Paste the drill template (supplied) to the desired mounting
position on the wall.
2. Drill the screw holes and the cable hole in the wall according to
the drill template.
Screw
Hole
Cable
Hole
Figure 2-7 Drill Template
3. Take apart the junction box, and fix the camera's mounting base
with three MP4 screws on the junction box's cover.
Junction Box
Cover
Mounting
Base
Figure 2-8 Fix screws on the junction box's Cover
