English 3
• Solvents and liquids containing solvents
• Viscous or sticky liquids or those that form residues (paints, grease)
• Use in food sector
This product may not be used under any circumstances:
• With external pressure sources
• For warehousing and storage of liquids
• As an eye wash
3.4 Items supplied
Tank with pump, hose with connectors, instructions for use.
Other system products approved for use with this product can be found at your local Hilti Store or at:
www.hilti.group | USA: www.hilti.com
4 Technical data
The tank material consists of steel with a polyester coating.
Tare weight
5.2 kg
Total content
13 ℓ
Maximum filling quantity
10 ℓ
Technical residual quantity
0.03 ℓ
Maximum operating pressure
6 bar
Maximum operating temperature
40 ℃
5 Preparations at the workplace
5.1 Assembling water supply unit
1. Check whether the tank, pump and hose are undamaged before assembly.
2. Connect the hose on the drain opening [1].
3. Pump up the empty water supply unit to 2 bar [2].
◁ The pressure must not drop by more than 0.5 bar within 30 minutes!
4. Pull the red button of the safety valve for checking [3].
◁ The pressure must be released.
