Step 3:
Step 2:
Step 4: Remove the front wheel hub axle.
Remove the plastic axle guards from the front wheel, being careful to avoid
contact with the brake rotor set.
Remove the front forks protection bar by manually pulling it straight up. Pull out
the red pad, which is used to protect the hydraulic brake caliper.
8
Step 5: Align the hole in the center of the tire with the hole in the hub axle. Then, insert
and secure the hub axle while ensuring that the brake pads of the front wheel are
properly engaged with the brake.
Tighten the front wheel nuts. Tighten the front wheel hub axle.Step 7:
NOTICE: please go to page 6 to check out the recommended torque values.
