CONTENTS
WARNING i
MAINS CABLE WIRING PLUG- i
SPARE PARTS I
SPECIFICATION 1
SAFETY 1
SET UP
Assembly and Transport 2
Installing Abrasive Disc 2
PREPARATION 2
OPERATION 2,3
FLOOR SANDING TECHNIQUE
Drum Floor Sander 4
Disc Floor Sander 4
Orbital Floor Sander 4
Hand Sanding 4
FLOOR TYPES
Sanding Plank & Strip Floors 4
Veneered, Laminated & Thinner Floors 4
Parquet & Block Floors 5
Between Coats of Finish (Varnish) 5
ABRASIVE PAPER GUIDE 6
SERVICE AND ROUTINE MAINTENANCE
General 7
Visual Inspection 7
Dust Control System 7
Drive 7
Lubrication 7
Care of Motor 7,8
Sanding Pad Removal & Replacement 8
Sanding Pad Trimming 9
Adjsuting the Castors 10
Electrical Testing 10
FAULT FINDING 11
HT PARTS DRAWING7-2 12
HT PARTS LIST7-2 13
HT CIRCUIT DIAGRAM7-2 14
DECLARATION OF CONFORMITY 15
SERVICE REPAIR& 16
WARNING
For safe operation of this machine, read and understand all instructions. Look for the ‘warning/caution’ symbol.
This symbol means that if you do not follow the instructions injury can occur to the operator and
damage to the machine and floor may result.
MAINS CABLE WIRING PLUG-
Hiretech reserves the right to make changes or improvements to it's products without prior notice.
®
i
NORTH AMERICA
BLACK
WHITE
GREEN
BRASS
TERMINAL
SILVER
TERMINAL
EU
BLUE
BROWN
GREEN/
YELLOW
UNITED KINGDOM
BLUE
(N - )NEUTRAL
BROWN
(L - )LINE
GREEN YELLOW/
(E - )EARTH
SPARE PARTS
Use Hiretech genuine spare parts only for service and repair. Use of non-approved parts will void the product
warranty. See the back cover of this manual for the terms and conditions of the Hiretech Limited Warranty.
To Next Page
