Installation EAGLE20/30
Release
06
04/2014
31
Figure 5: F/O SFP transceiver
Note: Only use Hirschmann SFP transceivers. See “Accessories” on
page 50.
2.5 Connecting the terminal blocks
Note: The working voltage is connected to the chassis through protective
elements exclusively.
2.5.1 Working voltage with the characteristic value K
Figure 6: Operating voltage characteristic value K: 3-pin terminal block with screw
locking
WARNING
ELECTRIC SHOCK
Never insert sharp objects (small screwdrivers, wires, etc.) into the
connection terminals for the supply voltage, the signal contact or the input,
and do not touch the terminals!
Start connecting the electrical wires solely if all the above requirements are
fulfilled.
See “Working voltage” on page 6.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
