Installation EAGLE20/30
Release 06 04/2014
For the operating voltage to be connected, perform the following steps:
 Remove the power connector from the device.
 Connect the protective conductor according to the pin assignment on the
device with the clamp.
 Connect the wires according to the pin assignment on the device with the
clamps.
 Connect the wires according to the pin assignment on the device with the
clamps.
 Fasten the wires connected by tightening the terminal screws.
2.5.2 Working voltage with the characteristic value C
You have the option of supplying the working voltage redundantly, without
load distribution.
Both working voltage inputs are uncoupled.
Figure 7: Operating voltage characteristic value C: 2-pin terminal block with screw
locking
Type of the voltages
that can be
connected
Specification of the working
voltage
Connections
DC voltage Rated voltage range DC
60 V ... 250 V
Voltage range DC incl.
maximum tolerances
48 V ... 320 V
+/L Plus terminal of the working
voltage
−/N Minus terminal of the working
voltage
Protective conductor
AC voltage Rated voltage range AC
110 V ... 230 V, 50 Hz ... 60 Hz
Voltage range AC incl.
maximum tolerances
88 V ... 265 V, 47 Hz ... 63 Hz
+/L Outer conductor
−/N Neutral conductor
Protective conductor
Table 9: Operating voltage characteristic value K: type and specification of the
supply voltage, connections
−
+
