HIPER-Ring
Redundancy L2E
Release
4.1
03/08
2.2
Configuring HIPER-Ring Version 2 (MRP
19
If VLANs are configured, then in the “VLAN” frame you select
- VLAN ID 0, if the MRP-Ring configuration is not to be assigned to
a VLAN.
Note the VLAN configuration of the ring ports. Then select for the
ring ports
- VLAN ID 1 and
- VLAN membership U in the static VLAN table
- a VLAN ID >0, if the MRP-Ring configuration is to be assigned to
this VLAN.
Select this VLAN ID in the MRP-Ring configuration for all devices in
this MRP-Ring.
Note the VLAN configuration of the ring ports. For all ring ports in this
MRP-Ring, select
- this VLAN ID and
- VLAN membership U in the static VLAN table.
Select the desired value in the “Ring Recovery” frame for the device
for which you have activated the redundancy manager.
Note: Settings in the “Ring Recovery” frame are ineffective for devices
that are not the redundancy manager.
Note: If selecting the smaller value for the ring recovery does provide
the ring stability neccesary to meet the requirements of your network,
you select 500 ms.
Activate the function in the “Operation” frame.
Now you connect the line to the ring. To do this, you connect the two
devices to the ends of the line using their ring ports.
The displays in the “Information” frame mean:
– „“Redundancy guaranteed”: One of the lines affected by the function
can fail, whereby the redundant line will then take over the function
of the failed line.
– „“Configuration failure”: The function is incorrectly configured or
there is an error on ringport link.
