Rapid Spanning Tree
68
4.6
The Rapid Spanning Tree Protocol
Redundancy L2E
Release
4.1
03/08
Figure 37: Display: Priority, MAC Address, Topology Changes and Time since
last change
If required, change the values for “Hello Time”, “Forward Delay” and
“Max. Age” in the root Switch. The root Switch then transfers this
data to the other Switches. The dialog displays the data received
from the root Switch in the left column. In the right column you enter
the values which shall apply when this Switch becomes a root
Switch. For the configuration, take note of table 13.
