Specications
ML22C User Manual, 99176B, September 2021 29
Physical
Enclosure Type Panel mount; rear collar compresses gasket against panel (5/16"
maximum panel thickness); held by 14 M5 studs
Panel Rating (with proper
installation)
Built to IP65/IP66 standards
• NEMA/UL Type 12/4 (Black Powder-Coated Faceplate)
• NEMA/UL Type 12/4/4X (Stainless Steel Faceplate)
Depth • Total Product Depth – 53�8 mm (2�12")
• Depth Behind Front Edge of Panel – 46.7 mm (1.84")
NOTE: Design to maximum depth of 69.0 mm (62.0 mm behind
front edge of panel) to ensure future compatibility with later
revisions and replacement units�
Front Bezel Outside
Dimensions (W x H x D)
558�8 mm x 374�7 mm x 7�1 mm (22�00" x 14�75" x 0�28") (not
including gasket)
Cutout Dimensions
(W x H)
528�7 mm x 342�3 mm (20�81" x 13�48"); ± 0�5 mm (0�020")
Net Weight 8.62 kg (19 lbs.)
Shipping Weight 10.43 kg (23 lbs.)
Electrical
Monitor Input • AC power models – 100 to 240 VAC, 1�5/0�75 A, 60/50 Hz
• DC power models – 9�6 to 36�6 VDC, 2�5 to 0�65 A, Class 2
or SELV/LPS
Power Consumption ~ 26 W
Power Consumption
(Standby mode)
< 0�5 W
