Installation Instructions
ML22C User Manual, 99176B, September 2021 9
Video Connection
The HIS-ML22 supports digital video through its DVI port, and analog video through its VGA port.
After selecting the appropriate interface, connect one end of your video cable to the input port on
the rear of the monitor and secure the screw locks to ensure adequate strain relief� Connect the
other end to the appropriate port on your host computer or other video source�
HAZ
LOC
NOTE: If this step is not performed, the product will not comply with Class I,
II, III, Division 2 Hazardous Location requirements.
TIP!
If the video source has an HDMI or DisplayPort connection, this can be converted
for use with the DVI video port using a simple adapter�
If the video source has a 5 wire analog RGB video output, this can be converted for
use with the VGA video port using a simple adapter�
Certied adapters are available from Hope Industrial Systems. Contact our sales
team for more information�
Power Connection
The HIS-ML22 is available with either AC or DC power input.
AC power input models are powered by 100 to 240 VAC, 1�5/0�75 A, 60/50 Hz� Loosen the
retaining clip for the power cable on the rear of the monitor. Connect the AC power cable to the
power input port on the monitor then retighten the retaining clip. Connect the other end into a
nearby outlet�
HAZ
LOC
NOTE: If this step is not performed, the product will not comply with Class I,
II, III, Division 2 Hazardous Location requirements.
