HIS ML19-D - Specifications

16
Specifications
Display
Type
Thin-film transistor (TFT) Active Matrix Liquid Crystal
Size
19.0” diagonal
Image size
14.81” (376.32mm) x 11.87” (301.06mm)
Native resolution
SXGA (1280 x 1024) @ 60 Hz
Plug and Play
DDC1/2B compatible
Minimum resolution
VGA (640 x 480)
Pixel pitch
0.294mm (H) x 0.294 mm (V)
Number of colors
16.7M (24 bit)
Viewing Angle (Hori/Vert)
170
°
/ 160
°
, typical
Brightness (white)
300 nits (cd/m
2
) min
Contrast ratio
1000:1 min.
Back light
4 CCFTs (Cold Cathode Fluorescent Tube);
50,000 hours, half-life; replaceable
Screen protector (when
not shipped with touch-
screen)
Tempered glass to ANSI-Z97.1 SPEC; AR coated on both
sides; 98% Transmission of light; 99% Reduction of glare;
53% UV blocking; 30% NIR Blocking
Video
Input connector
HD-15
Input signal format
RGB analog (0.7/1.0 Vp-p, 75 ohms), separate sync
Horizontal scan 30kHz – 82kHz
Vertical scan 50 Hz – 75 Hz
Supported Video Stan-
dards
1280 x 1024 @ 60, 75 Hz
1024 x 768 @ 60, 70, 75 Hz
800 x 600 @ 56, 60, 72, 75 Hz
640 x 480 @ 60, 75 Hz
720 x 400 @ 70 Hz
Response rate (typical) 5 ms, typical
