Enclosure
Type
Panel mount; rear collar compresses gasket against panel,
held by 12 M5 studs
Panel rating
NEMA 12/4/4X (with proper installation) – built to IP65 stan-
dards
Physical
Depth
2.43” (61.6 mm) behind panel maximum
Bezel
Powder Coated Carbon steel, black or Stainless Steel
Front bezel outside di-
mensions
19.0” (482.6mm) W x 15.7” (398.8mm) H x 0.28” (7.1mm)
thick (not including gasket)
Cutout dimensions
17.85” (453.4mm) W x 14.44” (366.8mm) H ; +/- .020”
Net weight
17 lbs.
Shipping weight
21 lbs.
VGA Pin assignment
Pin No. Signal Pin No. Signal
1
Red
9
No pin
2
Green
10
Ground
3
Blue
11
Ground
4
Ground
12
SDA
5
Ground
13
H. sync
6
Ground
14
V. sync
7
Ground
15
SCL
8
Ground
