3
Installing the Stand or Wall mount bracket
Wall mount hole pattern (mm) 100 × 200
Wall mount screw size (mm) M6
Installing the wall mount bracket
9.5 -11.5 mm
Wall Mount Bracket
Wall Mount Screw
Wall Mount Spacer
Rear cover of the TV
• The diameter and length of the screws differ depending on the wall mount bracket model.
• Wall mount bracket is optional, your device may not have wall mount bracket, please refer
to the actual accessories.
Follow instructions provided with the wall mount bracket.
NOTE
To Next Page
