3
Installing the Stand or Wall Mount Bracket
Wall-Mount hole pattern (mm) 100 × 200
Wall-Mount screw size M6
8.0~10.0mm
Wall-Mount Bracket
Screw
Spacer
The TV's rear cover
NOTES
Follow instructions provided with the Wall mount bracket.
Installing the Wall Mount Bracket
