4
TV Rear & Making Connections
TV Rear
NOTES
Check the jacks for position and type before making any connections.
Loose connections can result in image or color problems. Make sure
that all connections are tight and secure.
Not all A/V devices have the ability to connect to a TV, please refer to
the user’s manual of your A/V device for compatibility and connections
procedure.
Before connecting external equipment, remove the mains plug from the wall socket.
This may cause electric shock.
TV JACK
Outdoor
Antenna
Antenna Cable (75Ω)
or
ANT OUT
Cable
VHF/UHF Antenna
ANT
Connect an outdoor VHF/UHF antenna or cable.
ANT
(DVB-T/C)
(not included)
TV Bottom Panel
LAN
HDMI 2 / ARC
HDMI3
SERVICE
Y
L
P
B
R
P
R
COMP/AV IN
VIDEO
TV Side View
USB
DC 5V
0.5A(MAX)
ANT
HDMI 1/MHL
HEADPHONE
OPTICAL
To Next Page
