To Next PageTo Next PageWhat causes AC voltage to be abnormal in my Hisense AUC-24UR4SAEA1?
Abnormal AC voltage in your Hisense Air Conditioner can be due to: * AC voltage outside the range of 160V to 275V: This is a normal protection response; check the power supply. * Abnormal AC voltage in the sampling circuit on the drive board: Replace the drive board.
What causes temperature sensor fault for the outlet tube of the condenser in Hisense AUC-24UR4SAEA1?
A temperature sensor fault for the outlet tube of the condenser in your Hisense Air Conditioner may be due to: * Loose wiring: Reconnect the wiring of the temperature sensor for the outlet tube of the condenser. * Sensor failure: Replace the temperature sensor. * Sampling circuit issue: Replace the outdoor control board.
What causes temperature sensor fault for the inlet tube of the condenser in Hisense AUC-24UR4SAEA1?
A temperature sensor fault for the inlet tube of the condenser in your Hisense Air Conditioner might be caused by: * Loose wiring: Reconnect the wiring of the temperature sensor for the inlet tube of the condenser. * Sensor failure: Replace the temperature sensor. * Sampling circuit issue: Replace the outdoor control board.
What causes suction temperature sensor fault in Hisense AUC-24UR4SAEA1?
A suction temperature sensor fault in your Hisense Air Conditioner may be caused by: * Loose wiring: Reconnect the wiring of the suction temperature sensor. * Sensor failure: Replace the suction temperature sensor. * Sampling circuit issue: Replace the outdoor control board.
How to troubleshoot defrosting sensor fault in Hisense AUC-24UR4SAEA1 Air Conditioner?
A defrosting sensor fault in your Hisense Air Conditioner could be due to: * Loose wiring: Reconnect the wiring of the defrosting sensor. * Sensor failure: Replace the defrosting sensor. * Sampling circuit issue: Replace the outdoor control board.
What causes outdoor coil temperature sensor fault in Hisense AUC-24UR4SAEA1 Air Conditioner?
An outdoor coil temperature sensor fault in your Hisense Air Conditioner can be due to: * A loose connection of the outdoor coil temperature sensor: Reconnect the sensor. * A failure of the sensor itself: Replace the outdoor coil temperature sensor. * A failure in the sampling circuit: Replace the outdoor control board components.
What causes outdoor ambient temperature sensor fault in Hisense AUC-24UR4SAEA1?
An outdoor ambient temperature sensor fault in your Hisense Air Conditioner may arise from: * A loose connection of the outdoor ambient temperature sensor: Reconnect the sensor. * A failure of the sensor itself: Replace the outdoor ambient temperature sensor. * A failure in the sampling circuit: Replace the outdoor control board components.
How to fix Hisense Air Conditioner indoor EE fault?
An indoor EE fault in your Hisense Air Conditioner can be caused by: * A faulty EE component: Replace the EE component. * A failure in the EE control circuit of the control board: Replace the control board. * Incorrect insertion of the EE component: Reinsert the EE component correctly.
Why my Hisense AUC-24UR4SAEA1 Air Conditioner phase current imbalance fault?
A phase current imbalance fault in your Hisense Air Conditioner can be caused by: * Supply voltage fluctuations exceeding 4%: This triggers normal protection. Other potential solutions include: * Reconnect the wire according to the wiring diagram. * Replace the AC contactor. * Replace the compressor.
What to do if my Hisense Air Conditioner has communication failure between the indoor and outdoor unit?
If your Hisense Air Conditioner is experiencing communication failures between the indoor and outdoor units, it could be due to: * Incorrectly connected cables. Reconnect the connection cable according to the wiring diagram. * Loose communication cables. Reconnect the communication cables, ensuring connections are secure at both the control boards and terminals. * Faulty communication cables. Replace the communication cables. * A faulty indoor control board. Consider replacing the indoor control board. * A faulty outdoor control board. Replace the outdoor control board.
Key features of the DC inverter air conditioners, including space-saving and efficiency.
Overview of available models categorized by type and capacity.
Guide to understanding the structure and meaning of model numbers.
Visual representations of various indoor unit types and their configurations.
Detailed technical specifications for duct type air conditioners.
Detailed technical specifications for cassette type air conditioners.
Detailed technical specifications for ceiling & floor type air conditioners.
Provides dimension drawings and layout for indoor units of various types.
Provides dimension drawings and layout for outdoor units of various models.
Illustrates refrigerant piping circuits for different model capacities.
Details maximum refrigerant pipe length and height difference limits.
Presents electrical wiring diagrams for different unit types and models.
Shows air flow vs. static pressure curves for duct type units.
Displays cooling capacity performance curves at various temperatures.
Shows wiring diagrams for indoor unit control boards across different types.
Illustrates indoor unit control board layouts for various types and models.
Explains outdoor unit dip switch settings for various models and configurations.
Details the function and operation of the outdoor unit's digital display and buttons.
Describes how to adjust static pressure for duct type indoor units via terminals.
Outlines procedures for adjusting internal control parameters via the remote controller.
Provides resistance tables for various sensors at different temperature points.
Details major parameters and functions of the indoor unit controller, including modes and timers.
Explains control functions, protections, and operation modes for the outdoor unit.
Guide on how to retrieve fault codes from indoor and outdoor units using various methods.
Explains how outdoor units display fault codes via LEDs and digital tubes.
Describes fault code indications via driver board flashing lamps for specific models.
Table listing outdoor unit fault codes, possible reasons, and recommended solutions.
Provides a guide and flowchart for checking the refrigerant system's status.
Details testing procedures and resistance values for indoor fan motors.
Explains motor examination and repair with circuit diagrams for outdoor fan motors.
Outlines compressor examination and repair procedures with wiring diagrams.
Lists familiar errors related to inductance and testing.
Describes resistance testing procedures for step motors.
Explains fuse continuity checking procedures using a multimeter.
Details how to test capacitors using a multimeter.
Key features of the DC inverter air conditioners, including space-saving and efficiency.
Overview of available models categorized by type and capacity.
Guide to understanding the structure and meaning of model numbers.
Visual representations of various indoor unit types and their configurations.
Detailed technical specifications for duct type air conditioners.
Detailed technical specifications for cassette type air conditioners.
Detailed technical specifications for ceiling & floor type air conditioners.
Provides dimension drawings and layout for indoor units of various types.
Provides dimension drawings and layout for outdoor units of various models.
Illustrates refrigerant piping circuits for different model capacities.
Details maximum refrigerant pipe length and height difference limits.
Presents electrical wiring diagrams for different unit types and models.
Shows air flow vs. static pressure curves for duct type units.
Displays cooling capacity performance curves at various temperatures.
Shows wiring diagrams for indoor unit control boards across different types.
Illustrates indoor unit control board layouts for various types and models.
Explains outdoor unit dip switch settings for various models and configurations.
Details the function and operation of the outdoor unit's digital display and buttons.
Describes how to adjust static pressure for duct type indoor units via terminals.
Outlines procedures for adjusting internal control parameters via the remote controller.
Provides resistance tables for various sensors at different temperature points.
Details major parameters and functions of the indoor unit controller, including modes and timers.
Explains control functions, protections, and operation modes for the outdoor unit.
Guide on how to retrieve fault codes from indoor and outdoor units using various methods.
Explains how outdoor units display fault codes via LEDs and digital tubes.
Describes fault code indications via driver board flashing lamps for specific models.
Table listing outdoor unit fault codes, possible reasons, and recommended solutions.
Provides a guide and flowchart for checking the refrigerant system's status.
Details testing procedures and resistance values for indoor fan motors.
Explains motor examination and repair with circuit diagrams for outdoor fan motors.
Outlines compressor examination and repair procedures with wiring diagrams.
Lists familiar errors related to inductance and testing.
Describes resistance testing procedures for step motors.
Explains fuse continuity checking procedures using a multimeter.
Details how to test capacitors using a multimeter.
General| Refrigerant | R410A |
|---|---|
| Type | Split System |
| Cooling Capacity | 24000 BTU/h |
| Heating Capacity | 24000 BTU/h |
| Power Supply | 220-240V, 50Hz |
| Operating Temperature (Cooling) | 18°C to 43°C |
| Operating Temperature (Heating) | -7°C to 24°C |
