2. Unscrew and lift the lid from the rear and remove it, then lift the upper door and
place it on a padded surface to prevent it scratched.
3. Remove the upper hinge core, transfer it to left side and tighten securely, then put it
in a safe place.
4. Remove the two flange screw, then remove the middle hinge that hold the lower door
in place. Lift the lower door and place it on a padded surface to prevent scratching it.
5. Remove the hinge hole cover from the right holes as illustrated and transfer them to
the uncover hole at the left side.
12
