Installing your new appliance
5. Take out the lower drawer(5) by lifting
it up.
6. Remove the 2 screws(6) holding the
support with Phillips(+) screwdriver.
To reattach the doors and drawers after
you moved the appliance to its final
location, assemble the parts in reverse
order.
5
6
6
7. Remove the freezer door by lifting it
up.
Re-assemlbing the doors
Installing the water lines
10
In order for the ice maker to operate
properly, a water line is required. You
may need to purchase a water
purifying system to do that. The water
connection must be made by a
qualified plumber. If the refrigerator is
installed in an area with low water
pressure (below 30psi/207KPa), you can
install a booster pump to compensate
for the low pressure.
-the maximum inlet water pressure is
700kPa;
-the minimum inlet water pressure is
207kPa.
