20
① part ②, and part ③ by unscrewing
the screws ④.
① Screw cover
② Adjustable bottom feet part
③ Right lower hinge part
④ Special flange self-tapping
screw
7. Replace part ③ to the left side and
fixing it with the screws ④ . Replace
part ① and part ② to another side and
fixing it.
Note: 1. You need move hinge axis from
hole ① to ② , move adjustable bottom
feet part from hole ③ to ④ before
transfer.
8. Set the door into its new place making
sure the pin enters the bushing at the
lower frame section.
9. Replace the lid by fitting the upper
hinge core into the upper door's hole,
securing it with the 3 screws.
10. Put the screw hole cover and upper
hinge cover（left）as follow diagram.
