Hispacold ECOMASTER COMFORT - Operation in Sleeping Mode; Screen Contrast Adjustment

Page 16 of 19
MH-020-00-Ecomaster comfort user's manual Edited 06/04
Ecomaster Comfort
1. 17. Operation in Sleeping mode
If the control is in Sleeping mode (battery trip-switch off) a screen is displayed with the
following elements:
• The system time.
• If the preheater is activated, the preheater flame connected.
• If there is a preheater program, the preheater flame with the program number
(1 or 2).
• Whether the battery level is low.
Fig 4.4 Sleeping Screen
1. 18. Screen contrast adjustment.
Simultaneously press keys
(8) and (9) for 2 seconds to go to the contrast adjustment
screen:
Contrast adjustment screen
The passenger
(15) and (17) keys are used to increase or decrease the contrast
value between 15 and 62.
