Hitachi 32PD3000 - DC+5 V Series Regulator; Connectors

14
AV3000 AVC Unit Service Manual
SI-8033JD (I933).
Supply voltage: DC +5.3~40V at pin 1.
Pin
No.
Description
1 DC voltage input
4 Feedback input
Inputs
5 Output ON/OFF
Output 2 Switching output
5.6. DC+5V Series Regulator
SI-3050LSA (I932).
Supply voltage: DC +5.1~8V at pin 1 & 3.
Pin
No.
Description
1 DC voltage input
Inputs
3 DC voltage input
7 DC +5V output
Outputs
8 DC +5V output
5.7. Connectors
PSP connector for AV Board.
PFP1 connector for FC4 unit.
PFP2 connector for FC4 unit.
