Page #24 background imageLoading...
Page #24 background image
20
AV3000 AVC Unit Service Manual
7.3.2.
7-P Connector
Base SM3 1.5mm Pitch (PFP1)
Pin
No.
FC4
P002P
Pin Name
In/Out Function Notes
1 FA+6.0V I 6V power supply
460m
A
2 FA+6.0V I 6V power supply
3 GND - GND
4 GND - GND
5 FSTB+5V I Stand-by +5V 50mA
6 FSTB+5V I Stand-by +5V
7 GND - GND
7.3.3. 9-P Connector
Base SM3 1.5mm Pitch (PFP2)
Pin
No.
FC4
P003P
Pin Name
In/Out Function Notes
1 D+1.8V I 1.8V power supply 500mA
2 D+1.8V I 1.8V power supply
3 GND - GND
4 GND - GND
5 D+3.3V I 3.3V power supply 350mA
6 D+3.3V I 3.3V power supply
7 D+3.3V I 3.3V power supply
8 GND - GND
9 GND - GND
