AV3000 AVC Unit Service Manual
PST
0F 0F 0F Power save timer
FLA
OK OK OK
CAUTION!! Never press OK unless proper signal is
displayed, auto signal level adjustment activates.
MAX
READ READ READ Max signal level on screen
MIN
READ READ READ Min signal level on screen
SIG>
SNR
READ READ READ FC noise level indication
R1
READ READ READ Gain R; warm
PDP
Read/Write
13/20
1st D7:D0 /
D7:D0
G1
READ READ READ Gain G; warm
PDP
Read/Write
13/21
2nd D7:D0 /
D7:D0
COL>
B1
READ READ READ Gain B; warm
PDP
Read/Write
13/22
3rd D7:D0 /
D7:D0
R2
READ READ READ Gain R; normal
PDP
Read/Write
12/17
1st D7:D0 /
D7:D0
G2
READ READ READ Gain G; normal
PDP
Read/Write
12/18
2nd D7:D0 /
D7:D0
NOM>
B2
READ READ READ Gain B; normal
PDP
Read/Write
12/19
3rd D7:D0 /
D7:D0
R3
READ READ READ Gain R; cool
PDP
Read/Write
11/14
1st D7:D0 /
D7:D0
G3
READ READ READ Gain G; cool
PDP
Read/Write
11/15
2nd D7:D0 /
D7:D0
WAM>
B3
READ READ READ Gain B; cool
PDP
Read/Write
11/16
3rd D7:D0 /
D7:D0
MIS> RGB>
GSW
01 01 01 Gamma switch PDP 10 D3:D2
