35
AV3000 AVC Unit Service Manual
E2R
OK OK OK EEPROM reset
E2F
OK OK OK EEPROM factory setting
E2S
OK OK OK EEPROM is set to the shipment
E24
OK OK OK EEPROM in FC4 is initialised
E2>
EXS
OK OK OK Escape from service menu
Notes:
(*1): Maximum of 8 items on one page.
(*2): LTI picture mode.
(*3): CTI picture mode.
(*4): YNR picture mode.
(*5): CNR picture mode.
(*6): [ ]; Menu related value is decimal, it is ok to display in hex. E.g. [32] is centre of CONTRAST, [63] is MAX for CONTRAST.
(*7): [ ]; Menu related value is decimal, it is ok to display in hex. E.g. [11] is centre of BALANCE, [21] is MAX for TREBLE.
(*8): TDA9178 option. Values are fixed in this menu. No individual parameter on TC1~TC4 can be set.
(*9): WB Offset OFF/1/2/3 option.
(*10): Add 27 bytes.
