Hitachi 42PD5000 - Recommended Signal List

28
Signal Input (continued)
12345678
910111213141516
17 18 19 20 21 22 23
24
PRODUCT SPECIFICATIONS (continued)
DVI terminal (DVI-D)
Pin Input signal Pin Input signal
1
T.M.D.S. Data2-
14
+5V Power
2
T.M.D.S. Data2+
15
Ground (for+5V)
3
T.M.D.S. Data2/4 Shield
16
Hot Plug Detect
4
T.M.D.S. Data4-
17
T.M.D.S. Data0-
5
T.M.D.S. Data4+
18
T.M.D.S. Data0+
6
DDC Clock
19
T.M.D.S. Data0/5 Shield
7
DDC Data
20
T.M.D.S. Data5-
8
No Connect
21
T.M.D.S. Data5+
9
T.M.D.S. Data1-
22
T.M.D.S. Clock Shield
10
T.M.D.S. Data1+
23
T.M.D.S. Clock+
11
T.M.D.S. Data1/3 Shield
24
T.M.D.S. Clock-
12
T.M.D.S. Data3-
Frame GND
13
T.M.D.S. Data3+
With Digital RGB signal input (RGB1 input)
Recommended Signal List
No.
Signal mode
Horizontal frequency
(kHz)
Dot clock frequency
(MHz)
Remarks
Signal Name Resolution
Vertical frequency
(Hz)
1
VGA
640X400 70.08 31.47 25.18
2 640X480 59.94 31.47 25.18
3
W-VGA
864X480 60.00 31.02 33.75
4 864X480 59.94 31.47 34.24
WVGA type : On
5
VESA
640X480 72.81 37.86 31.50
6 640X480 75.00 37.50 31.50
7 640X480 85.01 43.27 36.00
8 800X600 56.25 35.16 36.00
9 800X600 60.32 37.88 40.00
10 800X600 72.19 48.08 50.00
11 800X600 75.00 46.88 49.50
12 800X600 85.06 53.67 56.25
13 1024X768 60.00 48.36 65.00
14 1024X768 70.07 56.48 75.00
15 1024X768 75.03 60.02 78.75
• Make sure that the signal of the equipment to be connected is compatible with the specifications of this list.
