Travelstar 5K100 Hard Disk Drive Specification
116
Table 75: Identify device information. (Part 5 of 7
* indicates the use of those parameters that are vendor specific.
** indicates a feature that is able to be unsupported by the Device Configuration Overlay command.
Word Content Description
86 3XXXH
*
*
*
Command set/feature enabled
15-14(=0) Reserved
13(=1) 1=FLUSH CACHE EXT command supported
12(=1) 1=FLUSH CACHE command supported
11(=x) 1=Device Configuration Overlay supported
10(=1) 1=48-bit Address feature set supported
9(=X) 1=Automatic Acoustic Management enabled
8(=X) 1=SET MAX security extension enabled
7(=X) 1=Address Offset mode enabled
6(=1) 1=SET FEATURES subcommand required to spin-up
5(=X) 1=Power-Up In Standby feature set has been
enabled via the SET FEATURES command
4(=0) 1=Removable Media Status Notification Feature Set
enabled
3(=X) 1=Advanced Power management Feature Set enabled
2(=0) 1=CFA Feature Set supported
1(=0) 1=READ/WRITE DMA QUEUED command supported
0(=0) 1=DOWNLOAD MICROCODE command supported
87 4023H Command set/feature enabled
15(=0) Always
14(=1) Always
13-6(=0) Reserved
5(=1) 1=General Purpose Logging feature set supported
4-2(=0) Reserved
1(=1) 1=SMART self-test supported
0(=1) 1=SMART error logging supported
88 XX3FH Ultra DMA Transfer mode (mode 5 supported)
15-14(=0) Reserved
13(=X) 1=UltraDMA mode 5 is selected
12(=X) 1=UltraDMA mode 4 is selected
11(=X) 1=UltraDMA mode 3 is selected
10(=X) 1=UltraDMA mode 2 is selected
9(=X) 1=UltraDMA mode 1 is selected
8(=X) 1=UltraDMA mode 0 is selected
7- 6(=0) Reserved
**5(=1) 1=UltraDMA mode 5 is selected
**4(=1) 1=UltraDMA mode 4 is supported
**3(=1) 1=UltraDMA mode 3 is supported
**2(=1) 1=UltraDMA mode 2 is supported
**1(=1) 1=UltraDMA mode 1 is supported
0(=1) 1=UltraDMA mode 0 is supported
89 XXXXH Time required for security erase unit completion
Time= value (XXXXh)*2 [minutes]
90 0000H Time required for Enhanced security erase completion
0000 : Not supported
